Oso 1.1 Complete E-Bike - 2025

Highlights

Description

CLEAN INTERFACE
They removed the Kiox display and front light for an elegant and clutter-free handlebar set up. The Oso controller is now an integrated part of the frame and sits flush in the top tube. Paired with a wireless mini-remote on the bars, this brings a sleeker look and simpler interface, with no extra wires going between the frame and handlebar.

LIGHTS WHEN YOU NEED THEM
Ibis has listened to your preferences, and it's even easier to choose if you want a full time front light or not. They pre-wired the bike so you can add the included Lupine SL F Nano 900 lumen headlamp making it ride ready for dawn patrol or when you're racing the sunset home. The Oso comes with a Lupine C14 taillight (seat collar + rear tail light combo). This 45 lumen taillight is bright enough to be seen in traffic or to help guide your friends home after dark. The Lupine C14 taillight can also be removed and
replaced with your seat collar of choice.

PRECISION LAYUP
With increased stiffness throughout the frame, the Oso delivers a more precise and confident ride. The updated carbon fiber layup is optimized for torsional stiffness while retaining a compliant rear end.

UPGRADED MOTOR GUARD AND DOWNTUBE PROTECTION
They beefed up the downtube and motor guards, with double the thickness and a toughened material. Stronger protection for more peace of mind.

TRIED AND TRUE BOSCH PERFORMANCE
The updated Oso 1.1 utilizes the vetted Generation 4 Bosch Performance Line CX motor, giving you smooth, responsive power with 85 Nm of torque. It’s paired with a UL-certified 750 Wh battery (or 625 Wh on the small size). Bosch backs their system with a two-year warranty and excellent customer service. They have also expanded their Bosch service to international customers with a dedicated Ibis expert.

SUSPENSION
The Oso’s dw-link suspension delivers an effortless, no-bob feel, with efficient power transfer, whether you’re charging uphill or down. With 155mm of rear travel that can be converted to 170mm, the bike, the bike soaks up rough terrain and handles in a smooth, playful, and engaging manner

Frame Material:	Carbon
Wheel Size:	29", Mixed: 29" front/27.5" rear
Rear Axle Standard:	12x148mm Boost
Rear Shock:	Fox Float X2 Performance Elite
Rear Shock Size:	205mm x 60mm
Rear Suspension Travel:	155mm
Headset:	Cane Creek 40
Headset Standard:	ZS44mm/ZS56mm
Fork:	Fox 38 Performance,170mm 29"
Fork Axle:	15x110mm Boost
Wheelset:	Ibis Blackbird Send SM-MD: F-29”/R-27.5”, LG-XL: F/R-29”
Front Tire:	Maxxis Assegai 29x2.5", 3C MaxxGrip, DH
Rear Tire:	Maxxis Minion DHR II, SM-MD: 27.5" x 2.4", Lg-XL: 29" x 2.4", 3C MaxxGrip, DH
Crankset:	SRAM X1 E-MTB, 34t Steel Ring
Chainguide:	Ibis top guide
Chain:	SRAM GX Eagle Transmission
Rear Derailleur:	SRAM GX Eagle Transmission
Cassette:	SRAM GX, Transmission 1052T
Seatpost:	Bike Yoke Revive SM: 125mm, MD: 160mm, LG: 185mm, XL: 213mm
Seat:	SDG Bel-Air V3
Shifters:	SRAM GX Eagle Transmission Pod Controller
Handlebar:	Blackbird Carbon 800mm
Stem:	Ibis 31.8mm SM-MD: 40mm, LG-XL: 50mm
Grips:	Lizard Skin Charger EVO
Brakes:	Shimano XT M8120 4-Piston
Water Bottle Cage Mounts:	Yes, 26oz on MD/LG/XL and 21oz on SM
Motor:	Bosch Performance Line CX
Battery:	Removable Bosch Powertube 750Wh MD/LG/XL and 625Wh on SM
Intended Use:	DH/FR
Warranty:	Lifetime frame warranty, lifetime replacement on bushings Two year electronics warranty through Bosch

Size	SM	MD	LG	XL
Reach	430	460	500	540
Stack	621	635	650	665
Top Tube	573	607	638	669
Wheelbase	1206	1242	1294	1341
Head Tube°	64°	64°	64°	64°
Head Tube	90	106	122	139
Seat Tube°	77°	77°	78°	79°
Seat Tube	394	414	414	427
BB Height	341	341	340	340
BB Drop	14	14	31	28
Standover	677	714	729	731
Chainstay	439	439	444	444
