Ibis
Ripmo V3 Frame - 2025
Pickup available at our Bellingham Store
Usually ready in 4 hours
Ripmo V3 Frame - 2025
Purple / SM
Fanatik Bike
Pickup available, usually ready in 4 hours
1812 N. State St.
Bellingham WA 98225
United States
Color:Purple
Size:SM
Quantity:
Choose options
Color:Purple
Size:SM
Quantity:
Color:Purple
Size:SM
Quantity:
Ripmo
Carbon
Material
29" | MX
Wheel Size
150
Rear (MM)
160
Front (MM)
Highlights
- Size Specific Everything
- Flip Chip for 27.5”/29” mixed (MX) wheels
- Internal Frame Storage
- DW-Link
Description
BUILT TO RIP
The Ripmo isn’t just a bike; it’s a legend. With multiple “Best in Test” awards
and years of high level competition at the notoriously brutal Enduro World Series, it’s the ultimate trail slaying machine. How do you improve on that? The Ripmo is loaded with new features internal downtube storage, a flip chip for mixed wheels, a slacker head angle, and increased coil compatibility. We’ve also expanded our sizing options and added size specific details—right down to the bottom bracket height.
| Frame Material: | Carbon |
| Wheel Size: | 29", MX (29"/27.5") |
| Front Suspension Travel: | 160mm |
| Rear Suspension Travel: | 150mm |
| Rear Shock: | Fox Float X, Factory Series, 2-Pos Adj. w/EVOL |
| Rear Shock Size: | 230mm x 60mm |
| Rear Axle Width: | 12x148mm Boost |
| Included Headset: | Cane Creek 40 |
| Headset Standard: | ZS44mm/ZS56mm |
| Brake Mount Type: | Post-Mount 180mm |
| Min Rear Rotor Size: | 180mm |
| Max Rear Rotor Size: | 220mm |
| Seat Post Diameter: | 34.9mm |
| Frame Storage: | Large Internal frame storage with easy access door |
| Frame Storage Bag: | Two sustainably sourced internal frame bags produced in partnership with Cotopaxi |
| Water Bottle Cage Mounts: | One bottle mount: 22oz bottle on size small, 26oz on all other sizes |
| Intended Use: | AM/Enduro |
| Warranty: | Lifetime + Lifetime replacement on bushings |
160mm FORK (575mm AXLE TO CROWN)
| Size | S | M | XM | L | XL |
|---|---|---|---|---|---|
| Reach | 436 | 456 | 478 | 506 | 540 |
| Stack | 616 | 622 | 633 | 643 | 654 |
| Top Tube | 578 | 605 | 630 | 655 | 685 |
| Wheelbase | 1195 | 1219 | 1249 | 1286 | 1329 |
| Head Tube° | 64.5°° | 64.5°° | 64.5°° | 64.5°° | 64.5°° |
| Head Tube | 85 | 95 | 110 | 125 | 140 |
| Seat Tube° | 77°° | 76.5°° | 76.5°° | 77°° | 77.5°° |
| Seat Tube | 395 | 400 | 415 | 457 | 477 |
| BB Height | 338 | 341 | 344 | 349 | 350 |
| BB Drop | 36 | 33 | 30 | 27 | 24 |
| Standover | 693 | 734 | 757 | 772 | 784 |
| Chainstay | 432 | 432 | 436 | 438 | 440 |
Size Guide
| Size | S | M | XM | L | XL |
|---|---|---|---|---|---|
| Height | 152 - 168 | 165 - 175 | 173 - 183 | 180 - 191 | 188 - 201 |
