Ibis
Ripmo V3 XT Complete Bike - 2025
Pickup available at our Bellingham Store
Usually ready in 4 hours
Ripmo V3 XT Complete Bike - 2025
Purple / SM (MX)
Fanatik Bike
Pickup available, usually ready in 4 hours
1812 N. State St.
Bellingham WA 98225
United States
Color:Purple
Size:SM (MX)
Quantity:
By purchasing this item, loyalty members will earn 6,499 loyalty points
Read more
Login to earn points
Read more
Login to earn points
Choose options
Color:Purple
Size:SM (MX)
Quantity:
Color:Purple
Size:SM (MX)
Quantity:
Highlights
- Size Specific Everything
- Flip Chip for 27.5”/29” mixed (MX) wheels
- Internal Frame Storage
- DW-Link
Description
BUILT TO RIP
The Ripmo isn’t just a bike; it’s a legend. With multiple “Best in Test” awards
and years of high level competition at the notoriously brutal Enduro World Series, it’s the ultimate trail slaying machine. How do you improve on that? The Ripmo is loaded with new features internal downtube storage, a flip chip for mixed wheels, a slacker head angle, and increased coil compatibility. We’ve also expanded our sizing options and added size specific details—right down to the bottom bracket height.
| Frame Material: | Carbon |
| Wheel Size: | 29", Mixed: 29" front/27.5" rear |
| Rear Axle Standard: | 12x148mm Boost |
| Rear Shock: | Fox Float X, Factory Series, 2-Pos Adj. w/EVOL |
| Rear Shock Size: | 230mm x 60mm |
| Rear Suspension Travel: | 150mm |
| Headset: | Cane Creek 40 |
| Headset Standard: | ZS44mm/ZS56mm |
| Fork: | Fox Float 36, Factory Series, GripX, 160mm, 29” |
| Fork Axle: | 15x110mm Boost |
| Wheelset: | Blackbird Send Alloy, 32 Hole, S-M F: Send I 29” R: Send II 27.5”, XM-XL F: Send I 29” R: Send II 29” |
| Front Tire: | Maxxis DHF, 29”x 2.5”, Exo+ |
| Rear Tire: | S-M: Maxxis DHR2, 27.5” x 2.5”, Exo+ XM-XL: Maxxis DHR2, 29” x 2.5”, Exo+ |
| Crankset: | Shimano XT, M8120, 24mm Spindle, 30T Alloy Ring, S-M: 165mm, XM-XL: 170mm |
| Bottom Bracket: | Shimano XT MT800 |
| Chain: | Shimano XT M8100 |
| Rear Derailleur: | Shimano XT, M8100, Shadow Plus |
| Cassette: | Shimano XT, M8100, 10-51T |
| Seatpost: | Bike Yoke Revive Dropper, S: 125mm, M: 160mm, XM: 185mm, L-XL: 213mm |
| Seat Post Diameter: | 34.9mm |
| Seat: | WTB Silverado, Fusion, 142mm |
| Shifters: | Shimano XT, M8100 |
| Handlebar: | Blackbird HiFi, 35mm, 800mm |
| Stem: | Blackbird, 35mm, S-M: 35mm, XM-XL: 50mm |
| Grips: | Lizard Skin Charger Evo |
| Brakes: | Shimano XT, M8120, 4-Piston |
| Intended Use: | AM/Enduro |
29" - 160mm FORK (575mm AXLE TO CROWN)
| Size | S | M | XM | L | XL |
|---|---|---|---|---|---|
| Reach | 436 | 456 | 478 | 506 | 540 |
| Stack | 616 | 622 | 633 | 643 | 654 |
| Top Tube | 578 | 605 | 630 | 630 | 685 |
| Wheelbase | 1195 | 1219 | 1249 | 1286 | 1329 |
| Head Tube° | 64.5°° | 64.5°° | 64.5°° | 64.5°° | 64.5°° |
| Head Tube | 85 | 95 | 110 | 125 | 140 |
| Seat Tube° | 77°° | 76.5°° | 76.5°° | 77°° | 77.5°° |
| Seat Tube | 395 | 400 | 415 | 457 | 477 |
| BB Height | 338 | 341 | 344 | 349 | 350 |
| BB Drop | 36 | 33 | 30 | 27 | 24 |
| Standover | 693 | 734 | 757 | 772 | 784 |
| Chainstay | 432 | 432 | 436 | 438 | 440 |
Size Guide
| Size | S | M | XM | L | XL |
|---|---|---|---|---|---|
| Height | 152 - 168 | 165 - 175 | 173 - 183 | 180 - 191 | 188 - 201 |
