Highlights
- Chromag's first all-aluminum bike for adults that is built to rip
- Long and slack geometry with upright riding position for sure footed versatility in demanding terrain
- Mullet only option with 170mm of travel front and rear
- Robust precision hardware and bearing at all pivot points
Description
Chromag made the Throwdown to support those who can’t get enough gravity, intended to be charged hard day after day. The Throwdown is the natural progression for a ripper grom from a Minor Threat or someone after a one bike quiver that loves a shuttle, a lift bump or even likes to earn their turns the hard way.
| Frame Material: | Aluminum |
| Wheel Size: | MX (29"/27.5") |
| Front Suspension Travel: | 170-180mm |
| Rear Suspension Travel: | 170mm |
| Rear Shock: | RockShox Vivid Air Ultimate |
| Rear Shock Size: | 205mm x 65mm |
| Rear Shock Hardware: | 8x20mm |
| Rear Axle Width: | 12x148mm Boost |
| Headset Standard: | ZS44mm/ZS56mm |
| BB Standard: | 73mm BSA |
| ISCG Tabs: | ISCG '05 3-Bolt |
| Brake Mount Type: | Post-Mount 180mm |
| Min Rear Rotor Size: | 180mm |
| Max Rear Rotor Size: | 220mm |
| Maximum Tire Size: | 27.5 x 2.5" |
| Seat Post Diameter: | 31.6mm |
| Seat Clamp Diameter: | 35mm |
| Frame Storage: | Accessory mount under top tube |
| Water Bottle Cage Mounts: | 1 set on downtube |
| Intended Use: | DH/FR, AM/Enduro |
| Warranty: | 3 years |
| Size | SM | MD | M/L | LG | XL |
|---|---|---|---|---|---|
| Reach | 445 | 465 | 485 | 505 | 525 |
| Stack | 624 | 633 | 642 | 651 | 651 |
| Top Tube | 576 | 599 | 621 | 643 | 663 |
| Wheelbase | 1224 | 1249 | 1273 | 1304 | 1324 |
| Head Tube° | 63.5° | 63.5° | 63.5° | 63.5° | 63.5° |
| Head Tube | 105 | 105 | 115 | 125 | 125 |
| Seat Tube° | 78° | 78° | 78° | 78° | 78° |
| Seat Tube | 350 | 380 | 410 | 440 | 470 |
| BB Height | 344 | 344 | 344 | 344 | 344 |
| BB Drop | 22 | 22 | 22 | 22 | 22 |
| Standover | 686 | 745 | 745 | 774 | 804 |
| Chainstay | 435 | 435 | 435 | 442 | 442 |
