Specialized Stumpjumper 15 Ohlins Coil Complete Bike - 2025
Specialized Stumpjumper 15 Ohlins Coil Complete Bike - 2025
Stumpjumper 15 is here to obliterate every trade-off in the trail game. Devour
bumps like a big bike? Check. Short-travel control, playfulness, and efficiency? Double
check. How about a heaping helping of personalization to make it perfect for the only
rider who really matters—you? Check, check, check
CAPABILITY: GENIE Shock Technology combines a poppy, playful ride with a bottomless DH feel.
ULTIMATE CONTROL: Measurably better traction than “Bike of the Year” Stumpjumper EVO.
UNMATCHED PERSONALIZATION: Six-way geometry adjustment, mixed wheel or 29”, tunable spring curve, and more.
GENIE—The Magic Carpet Ride: The biggest innovation on the Stumpjumper 15 is GENIE. This patent-pending air spring technology that they invented grants every trail rider’s three wishes: the feel and control of a coil spring, better bottom-out prevention than a standard air spring, and a tunable “platform” for a playful feel.
ILLUMINATING GENIE: GENIE combines the control-enhancing linear
spring rate of a coil spring through the “bump zone” with the progressive spring rate of
an air spring at the end of the stroke to avoid bottom-outs. Truly, it's the best of both
worlds – coil and air – with extra tunability. Say goodbye to compromises and hello to
the future of riding.
WHAT BUMP? With 16.3% better bump force management than a traditional air-sprung shock, GENIE makes the Stumpy 15 ride like a bike with more travel. For example, the Stumpjumper 15 (with 145 mm rear wheel travel) and the
Enduro (170 mm travel) both use 101 mm of travel to absorb a 1080 N bump
force.
TRACTION GALORE: Extensive field testing proves that Stumpjumper 15
with GENIE delivers 57% better traction than a standard air-sprung shock because
GENIE technology gives you supple, coil-like performance, which keeps the wheel in
contact with the ground a greater percent of the time than a typical air spring
would.
BYE, BYE, BOTTOM-OUTS: 39% fewer bottom-outs than a standard air
spring. During big hit events, you benefit from the rising rate in the last 30% of the
GENIE stroke. Because of this two-stage, pronounced rising rate, GENIE reduces the
frequency and severity of bottom-outs.
HONED GEOMETRY: This bike’s geometry delivers big bike capability when you need it, a nimble feel in tight sections, and lively, efficient climbing manners. The generous cockpit centers you on the bike, optimizing traction and corner control. The low bottom bracket, slack head tube angle, and optimized fork offset keep things stable in the rough.
RIDE YOUR WAY: The Stumpjumper 15 seamlessly integrates benchmark geo adjustability, making it the most personalizable trail bike ever. Six distinct geometry settings allow you to hone performance for any style, any terrain. Head angle and bottom bracket height can be fine-tuned for stability or clearance.
WHEEL CHOICE: With their aftermarket shock links, you can choose between big wheels front and rear or mix things up with a 27.5” rear for a more responsive and playful ride. No matter what you choose, geometry is unaffected.
CARRY IT ALL: SWAT 4.0 on Stumpjumper 15 elevates downtube storage, an innovation they pioneered. It’s the smoothest operating, most weather-resistant, flush-mounted system ever.
MORE RELENTLESS THAN YOU: Their full suspension bikes are built to be relentless, designed to endure years of hard riding and backed by the best support and policies to keep you on the trail. Their unbeatable lifetime, no-questions-asked replacement of suspension pivot bearings to the original owner is just one way they've got you covered.
Features
- Lightweight FACT 11m carbon chassis and rear-end
- Incredibly tough Roval Traverse wheels with DT Swiss 370 hub
- Premium suspension support from an Öhlins TTX 22 M Coil, Ride Dynamics tuned
- Plow through anything with a 160mm Öhlins RXF38 M.2 29 fork
- Reliable and smooth shifting from SRAM GX Eagle AXS T-Type drivetrain
- Powerful brakes with great hand feel thanks to TRP DH-R EVO 4-piston brakes
- Adjustable travel PNW LOAM dropper post
- Lifetime replacement of suspension pivot bearings to the original owner
- SWAT Frame Storage
Tech Specs
Frame Material: | Carbon |
Wheel Size: | Mixed: 29" front/27.5" rear |
Rear Axle Standard: | 12x148mm Boost |
Rear Shock: | Öhlins TTX 22 M Coil, Ride Dynamics trail tune, external rebound adjust, external high and low speed compression adjustment, 210x55 |
Rear Shock Size: | 210mm x 55mm |
Rear Suspension Travel: | 145mm |
Headset: | Specialized Angle Adjust |
Fork: | Öhlins RXF38 M.2 29, TTX Twin Tube Damping, external low speed rebound adjust, external high and low speed compression adjustment, 15x110mm, 44mm offset, 160mm of travel |
Fork Axle: | 15x110mm Boost |
Wheelset: | Specialized Roval Traverse hookless alloy on DT Swiss 370 28h | Front: 29" | Rear: 27.5" |
Front Tire: | Specialized Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" |
Rear Tire: | Specialized Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5"x2.3" |
Crankset: | SRAM GX Eagle Transmission Crankset, 32T ring, Integrated Guard, 55mm Chainline, S2-S3:165mm, S4-S6: 170mm |
Chainguide Tabs: | ISCG '05 3-Bolt |
Bottom Bracket: | SRAM DUB, BSA 73mm Wide, Threaded |
BB Standard: | 73mm BSA |
Chain: | SRAM GX Eagle Transmission Flattop Chain |
Rear Derailleur: | SRAM GX Eagle Transmission Derailleur |
Cassette: | SRAM GX Eagle Transmission Cassette, 12spd, 10-52t |
Seatpost: | PNW Loam Dropper, tool-less travel adjust, Range lever, 34.9, S2: 150mm, S3: 170mm, S4-S6: 200mm |
Seat Post Diameter: | 34.9mm |
Seat Post Clamp Diameter: | 38.6mm |
Seat: | Specialized Bridge Comp, Hollow Cr-mo rails, S2: 155mm, S3-S6: 143mm |
Shifters: | SRAM AXS POD Controller |
Handlebar: | Deity, Racepoint, 5-degree upsweep, 9-degree backsweep, 810mm width, S2: 25mm rise; S3-S6: 38mm rise |
Stem: | Deity, 35mm clamp, 35mm length |
Grips: | Diety, Supracush, Black |
Brakes: | TRP DH-R EVO, 4-piston caliper, hydraulic disc, Front: 220mm | Rear: 203mm |
Water Bottle Cage Mounts: | SWAT Bottle Storage |
Intended Use: | Trail/AM |
Warranty: | 2 years or Lifetime with registration |
Specs subject to change without notice. Please check with manufacturer for the most up-to-date information.
Geometry
mm / inches
160mm Fork
Insertion
Sizing
cm / ft
Size | S2 | S3 | S4 | S5 | S6 |
---|---|---|---|---|---|
Rider Height (cm) | 157 - 173 | 165 - 180 | 173 - 188 | 177 - 193 | 188 - 198 |
