Turbo Vado 4.0 Step-Thru
Choose options
Description
Consider Vado your high-performance transportation bike, getting you where you’re going with an unmatched combination of speed, reliability, and confidence. Whether you load it up with your stuff, or jump on and go, commute to work, or ride to the gym, Vado’s full power and huge range will get you from ‘point A’ to ‘point B’ ASAP.
The Specialized Vado has everything you need for e-powered transport. It brings a balanced nature to the way it handles and superior levels of comfort. This is a true class leader of its type
| Frame Material: | Aluminum |
| Wheel Size: | 27.5" |
| Rear Axle Standard: | 12x142mm |
| Fork: | SR Suntour MobieA32, 80mm travel, lockout, fender-mounts, integrated light mount |
| Fork Axle: | 15x100mm |
| Wheelset: | Shimano hubs x Specialized rims, 30mm, 32h |
| Tires: | Pathfinder Sport Reflect, 650Bx2.3 |
| Crankset: | Custom alloy forged crankarms, 170mm |
| Chain: | Shimano LG |
| Rear Derailleur: | Shimano CUES 9-Speed |
| Cassette: | Shimano CUES 9-speed, 11-41t |
| Seatpost: | Suspension, 40mm travel |
| Seat Post Diameter: | 34.9mm |
| Seat: | Bridge Sport, Steel rails, 155mm |
| Shifters: | Shimano CUES 9-Speed with Optical Gear Display |
| Handlebar: | Specialized, alloy, 15-degree backsweep, 46mm rise, 31.8mm |
| Stem: | Specialized Flowset, 3D-forged alloy, 20-degree rise, 31.8mm clamp |
| Grips: | Specialized Body Geometry Contour |
| Brakes: | Shimano BR-MT200, hydraulic disc, 180mm rotors |
| Motor: | Specialized 2.0 |
| Maximum Power Output: | 250w |
| Maximum Motor Torque: | 70 Nm |
| Battery: | Specialized Internal |
| Battery Wattage: | 710Wh |
| Intended Use: | Commuter |
| Warranty: | Lifetime on frame, 2 years on battery and drive unit |
Size Small Geo
| Size | SM |
|---|---|
| Reach | 423 |
| Stack | 625 |
| Top Tube | 585 |
| Wheelbase | 1160 |
| Head Tube° | 68° |
| Head Tube | 135 |
| Seat Tube° | 75.5° |
| Seat Tube | 400 |
| BB Height | 285 |
| BB Drop | 70 |
| Standover | 618 |
| Chainstay | 470 |
| Trail | 96 |
